OptiDi is one of the kind diffuser giving your interior a unique aesthetics. It combines philosophy of minimalistic design and great acoustic properties. Its specific shape made of aluminium provides sound diffusion combined with efficient absorption in a lower frequency range. OptiDi providing a great visual effect and outstanding acoustical performance.

Sala prób z zastosowaniem dyfuzora akustycznego OptiDi
Sala prób z zastosowaniem dyfuzora akustycznego OptiDi
Sala prób z zastosowaniem dyfuzora akustycznego OptiDi
Sala prób z zastosowaniem dyfuzora akustycznego OptiDi
Aula wykładowa z zastosowaniem dyfuzora akustycznego OptiDi

Designed by:

AS Team

more
Architected Sound Team

Details

Technical drawing of OptiDi acoustic diffuser - cross section view and front view

Patterns:

OptiDi acoustic diffuser - positive version of pattern OptiDi acoustic diffuser - negative version of pattern

Dimensions:

150 × 1200 × 40 mm
max length: 6000 mm

Weight:

17 kg/m2

Material:

aluminium

Acoustic properties:

Designer:

Architected Sound Team

Country of production:

Poland

Category:

diffusion / absorption

Description:

OptiDi system diffuses sound in mid and high frequencies, most effectively as a combination of positive and negative modules. Due to internal filling and variable slots’ width, bass absorption may be adjusted to a particular frequency of choice. OptiDi is usually used on walls but it can be designed for ceilings or as a portable panel as well.

Sound absorption coefficient:

αw, max = 0,20

Application:

  • concert halls
  • philharmonic halls
  • theater halls
  • opera houses
  • rehearsal rooms
  • recording studios
  • control rooms
  • radio and TV emission rooms
  • lecture halls
  • classrooms
  • conference rooms
  • waiting rooms
  • offices
  • dedicated listening rooms

Custom-made:

Usually custom-made due to specific absorption needed.
Ceiling structure and mobile version possible. Various depth and bass absorption properties on demand.

Fire safety:

Made of materials with flammability class A0.

Additional information:

Optidi system was developed in cooperation with AGH University of Science and Technology.
Registered Community Design number: 004417723-0001 and 004417723-0002.

Sound absorption coefficients of
Architected Sound OptiDi

Architected Sound OptiDi acoustic diffuser - Graph of sound absorption coefficients

Practical sound absorption coefficient αp

frequency 1/1-okt.
125 Hz 0,60 0,55 0,00
250 Hz 0,45 0,50 0,05
500 Hz 0,20 0,20 0,05
1000 Hz 0,15 0,15 0,05
2000 Hz 0,15 0,15 0,10
4000 Hz 0,15 0,15 0,10
  • slit 1 mm + mineral wool 50 mm, o.d.s. 90 mm*
  • slit 1 mm + mineral wool 100 mm, o.d.s. 140 mm**
  • direct mounting, o.d.s. 55 mm*
  • * results obtained from analytical calculations
    ** measurement conducted in accordance to PN-EN ISO 354:2005

Sound scattering coefficients of
Architected Sound OptiDi

Architected Sound OptiDi acoustic diffuser - Graph of sound scattering coefficients

Sound scattering coefficient s

frequency 1/3-okt.
1000 Hz 0,05
1250 Hz 0,13
1600 Hz 0,28
2000 Hz 0,44
2500 Hz 0,53
3150 Hz 0,62
4000 Hz 0,82
5000 Hz 0,90
  • slit from 0 to 5 mm*
  • * measurement conducted in accordance to ISO 17497-1:2004

OptiDi system is possible to finish in any colour from RAL K7 Classic palette or wood–like varnish.
