Slotbar is a modular sound-absorbing system developed by Architected Sound. Uniquely arranged natural wooden bars absorb low tone resonance. Its properties result from specifically designed slot system which maintains optimum acoustic conditions and provides innovative shape. The whole structure guarantees absorption in low frequency range. SlotBar can be used as standalone system or in addition to OptiDi.

Simplicity is the key to brilliance!

Wizualizacja adaptacji akustycznej domowego biura z wykorzystaniem panelu akustycznego SlotBar
Wizualizacja adaptacji akustycznej sali z wykorzystaniem panelu akustycznego SlotBar
Wizualizacja adaptacji akustycznej sali z wykorzystaniem panelu akustycznego SlotBar
Wizualizacja adaptacji akustycznej sypialni z wykorzystaniem panelu akustycznego SlotBar
Wizualizacja adaptacji akustycznej sali z wykorzystaniem panelu akustycznego SlotBar
Wizualizacja adaptacji domowej sali odsłuchowej z wykorzystaniem panelu akustycznego SlotBar
Wizualizacja adaptacji akustycznej sali z wykorzystaniem panelu akustycznego SlotBar

Designed by

AS Team

more
Architected Sound Team

Details

Technical drawing of SlotBar acoustic panel system - cross section and front view

Examples of patterns:

An example of the arrangement of the SlotBar acoustic panel elements - sample A An example of the arrangement of the SlotBar acoustic panel elements - sample B An example of the arrangement of the SlotBar acoustic panel elements - sample C

Size:

150 × 1200 × 12 mm

Thickness:

Substructure with absorbing material (e.g. mineral wool) is 50-100 mm thick (depending on the absorption needed).
minimum thickness of a single element: 12 mm

Weight:

10 kg/m2 (substructure not included)

Material:

MDF

Acoustic properties:

Designer:

Architected Sound Team

Country of production:

Poland

Category:

absorption

Description:

SlotBar properties allow the absorption of sound in the low frequency range with relatively small thickness of the structure, which is particularly desirable in small sized studio rooms. It is possible to precisely design the range of sound absorption in the low frequencies due to specially developed slot system with a variable gap width, supported by the use of acoustic nonwovens and an invisible layer of material with appropriately selected acoustic properties. Optional installation of teletechnical, electrical equipment and executive modules inside the system.

Sound absorption coefficient:

αw, max = 0.60

Application:

  • concert halls
  • recording studios
  • home listening rooms
  • offices
  • conference room
  • classrooms in musical schools
  • consumer spaces
  • waiting rooms

Custom-made options:

Large diversity of sizes in design and installation solutions available, which enables designing and installing the module of external sizes required for current localization.

Fire safety:

Possibility of making the system out of materials with flammability class at least D-s1.

Sound absorption coefficients ofArchitected Sound SlotBar

Architected Sound SlotBar acoustic panel - sound absorption coefficients

Practical sound absorption coefficient αp

frequency 1/1-okt.
125 Hz 0,05 0,15 0,05 0,15
250 Hz 0,15 0,55 0,20 0,55
500 Hz 0,50 0,85 0,55 0,90
1000 Hz 0,75 0,90 0,85 0,95
2000 Hz 0,90 0,90 0,95 0,95
4000 Hz 0,90 0,85 0,95 0,95
  • percentage share of the slot 1%, mineral wool 100 mm, o.d.s. 112 mm*
  • percentage share of the slot 4%, mineral wool 50 mm, o.d.s. 62 mm*
  • percentage share of the slot 50%, mineral wool of high density 50 mm, o.d.s. 62 mm*
  • percentage share of the slot 50%, mineral wool of medium density 50 mm, o.d.s. 62 mm*

* results obtained from analytical calculations

Available in any colour from the RAL palette or natural veneer.
