Tilt Lite

Ikona symbolizująca zjawisko odbicia fali dźwiękowej

reflection

Ikona symbolizująca niskie tony fal dźwiękowych

low tones

Ikona symbolizująca średnie tony fal dźwiękowych

mid tones

Ikona symbolizująca wysokie tony fal dźwiękowych

high tones

Shape your space.

Tilt Lite is an extremely light wall acoustic system, created in order to properly direct the reflections of the sound wave. The 7° inclined mounting bracket enables the front plate to be directed in any direction. Tilt Lite is a universal and individually selected element of acoustic treatment of the interior, which allows you to create interesting visual forms.

Tilt Lite sound reflective panel in the waiting room
Tilt Lite sound reflective panel in the rehearsal room
Tilt Lite sound reflective panel in the concert hall
Tilt Lite sound reflective panel in the foyer wall

Designer
AS Team

More
Architected Sound Team

Details

Tilt Lite is a wall-mounted, multifunctional acoustic system that allows you to direct the sound wave in the desired direction. The Tilt Lite mounting bracket tilts the front plate at an angle of 7 ° to the wall surface. Due to easy installation and low weight, the Tilt Lite system can also be used in existing, finished interiors, both on walls and on doors. It is also very useful in cases where classic acoustic systems cannot be installed symmetrically.

Illustration of directing sound waves using Tilt Lite panels

Dimensions

  • square - 600 × 600 × 98 mm
  • triangle - 600 × 520 × 93 mm
  • semicircle - 600 × 300 × 79 mm

Weight

  • square - up to 3,9 kg
  • triangle - up to 2,2 kg
  • semicircle - up to 3,3 kg

Material

powder coated steel
front plate - HPL, PET

Designer

Architected Sound Team

Illustration of Tilt Lite panel assembly

Ilustration of Tilt Lite assembly

Colour guide of Tilt Lite is available on request.

  • concert halls
  • recording studios
  • dedicated listening rooms
  • conference rooms
  • lecture rooms
  • classrooms
  • waiting rooms
  • offices
  • consumer and public spaces

It is possible to make the Tilt Lite as a sound absorbing system using EcoPET as a front panel.

Technical drawing

 Technical drawing with dimensions of Architected Sound Tilt Lite sound reflective panel

Fire safety

Possibility of making the diffusing only system out of materials with flammability class B-s1, d0.

Thumbnail cover of brochure of Tilt Lite sound reflective panel
Thumbnail cover of product sheet of Tilt Lite sound reflective panel
Thumbnail cover of our products catalogue
Plik DAT
AS_CATT_library
Plik PWM
AS_MaterialBase_01.18_pack
