Aco-ustic Painting
Sound absorbing painting
Aco-ustic Painting is a sound-absorbing acoustic panel in the form of a picture, which can be ordered in the form of photo reproductions, graphics and paintings. The artists we work with decided to entrust us with their art, so that it would gain a new usable dimension in the form of acoustic panels. They are available in various formats to ensure the desired soundproofing effect and to fully meet the aesthetic value of the room.
The power of our acoustic works of art is the highest absorption class (Class A).
Fill your interior with any visual you imagined and benefit from its unexpected acoustic properties.
Designer
IAMC Team
and associated artist
Details
Aco-ustic Painting panels are designed to absorb a wide range of high and mid frequencies which reduces noise‑amplifying reverberation found in domestic and public spaces.
Dimension
Acoustic images are available in four standard sizes:
- 617 × 617 mm
- 617 × 864 mm
- 617 × 317 mm
- 617 × 1217 mm
It can be made to order in a custom size.
Real dimension may slightly differ from those presented above.
Thickness
45 mm
Pattern
Available in a broad range of artworks accessible on our artwork gallery or any custom pattern chosen by the customer.
Designer
IAMC Team and associated artists
Sound absorption coefficient
αw, max = 0.90 max absorption class A
Frame of Aco-ustic Painting
Exotic Abachi wood, oiled or stained to obtain the required colour.
Sample frame stain colours
Types of printing surface
Standard
Printed on a rough surface
with a slight satin gloss finish.
Eco
Printed on a matte surface
with a visible fiber structure.
Canvas Std
Printed on a textile material
with a herringbone weave.
Canvas Prem
Printed on a textile material
with a fine and irregular weave.
The installation of Aco-ustic Painting sound-absorbing panels is possible on any wall with the density and structure enabling the use of standard load-bearing elements
We pack all our paintings in a safe cardboard box that protects the contents during transportation.
Aco-ustic Painting is available as a single element in standard sizes or as a composition consisting of many components (set of two, three etc.). It can be made to order in non-standard size.
- rooms in houses and apartments (e.g. living room, bedroom, children's room, hall)
- hotel rooms and passageways
- theater halls
- dedicated listening rooms
- recording studios
- offices
- conference rooms
- consumer and public spaces
- lecture rooms
- classrooms
- waiting rooms
- consulting rooms
- food service areas
Sound absorption coefficient of Architected Sound Aco-ustic Painting
Practical sound absorption coefficient αp
| frequency 1/1-oct. |  |
|---|---|
| 125 Hz | 0.15 |
| 250 Hz | 0.55 |
| 500 Hz | 0.90 |
| 1000 Hz | 0.95 |
| 2000 Hz | 0.95 |
| 4000 Hz | 0.95 |
- thickness 45 mm
Sound absorption coefficient
sound absorption class A
Discover more
OptiDi
Sound diffuser system
OptiDi is an acoustic diffuser designed for specific performance goals. It gives interiors a distinctive character, combining minimalist aesthetics with excellent acoustic properties.
The system is made of specially profiled aluminium to provide sound diffusion in the mid and high frequency ranges, while also absorbing low frequencies. When designing the shape of OptiDi, our key objective was to achieve high sound diffusion efficiency with the smallest possible panel depth.
Every millimetre mattered to us.
Designer
AS Team
Details
OptiDi system diffuses sound in mid and high frequencies, most effectively as a combination of positive and negative modules. Due to internal filling and variable slots’ width, bass absorption may be adjusted to a particular frequency of choice. OptiDi is usually used on walls but it can be designed for ceilings or as a portable panel as well.
Size
150 × 1200 × 40 mm
Max lenght
- 7500 mm - colours from RAL K7 Classic palette
- 7000 mm - varnish
Weight
17 kg/m2
Material
aluminium
Designer
Architected Sound Team
Sound absorption coefficient
αw, max = 0.20
Additional information
Technical solution developed in cooperation with the AGH University of Science and Technology in Cracow.
Community design number: 004417723-0001 and 004417723-0002.
Registered Community Design
OptiDi is a product registered with EUIPO – the European Union Intellectual Property Office.
Community design numbers: 004417723‑0001 and 004417723‑0002
A Community design is a legally protected form of industrial design, registered with the European Union Intellectual Property Office (EUIPO), granting exclusive rights to its use across the entire European Union. This protection prevents unauthorized copying and exploitation by third parties, ensuring its originality and safeguarding the interests of its owner.
OptiDi system is possible to finish in any colour from RAL K7 Classic palette or wood–like varnish.
RAL K7 Classic
The most popular colours
Varnish
Non-binding color sample.
Production-related and/or application-related deviations are possible.
Before placing an order, please contact us at info@architected-sound.com in order to verify the colours and their availability.
- concert halls
- philharmonic halls
- theater halls
- opera houses
- rehearsal rooms
- recording studios
- control rooms
- radio and TV emission rooms
- lecture halls
- conference rooms
- dedicated listening rooms
A comprehensive acoustic system, individually designed to meet the required acoustic performance parameters.
Available in ceiling-mounted and mobile versions.
Different panel thicknesses are available, depending on the required level of low-frequency sound absorption.
Technical drawing
Fire safety
Made of materials with flammability class A1.
Sound absorption coefficients of Architected Sound OptiDi
Practical sound absorption coefficient αp
| direct mouting |
A-40 | C-50 | C-60 | C-100 |
|---|---|---|---|---|
| frequency 1/1‑oct. |
|
|
|
|
| 125 Hz | 0.05 | 0.60 | 0.70 | 0.45 |
| 250 Hz | 0.10 | 0.20 | 0.45 | 0.20 |
| 500 Hz | 0.25 | 0.05 | 0.15 | 0.05 |
| 1000 Hz | 0.20 | 0.10 | 0.10 | 0.10 |
| 2000 Hz | 0.15 | 0.15 | 0.15 | 0.15 |
| 4000 Hz | 0.20 | 0.20 | 0.20 | 0.20 |
- A-40: direct mounting, o.d.s. 40 mm*
- C-50: slit 1 mm + mineral wool 50 mm (35 kg/cbm), o.d.s. 90 mm*
- C-60: slit 3 mm + mineral wool 60 mm (35 kg/cbm), o.d.s. 100 mm*
- C-100: slit 1 mm + mineral wool 100 mm (35 kg/cbm), o.d.s. 140 mm*
* results obtained from analytical calculations
Sound scattering coefficients of Architected Sound OptiDi
Sound scattering coefficient s
| frequency 1/3-oct. |  |
|---|---|
| 1000 Hz | 0.05 |
| 1250 Hz | 0.13 |
| 1600 Hz | 0.28 |
| 2000 Hz | 0.44 |
| 2500 Hz | 0.53 |
| 3150 Hz | 0.62 |
| 4000 Hz | 0.82 |
| 5000 Hz | 0.90 |
- slit from 0 to 5 mm*
* measurement conducted in accordance to ISO 17497-1:2004
Discover more
OptiDi Panel
Sound diffuser panel
OptiDi Panel is a compact acoustic diffuser with a wide range of applications. Its unique shape and colour bring life to any interior, giving it a distinctive character by combining visual appeal with acoustic performance. Precisely formed from aluminium, it is available in two profiles and two thickness options, providing sound diffusion in the mid and high frequency ranges, with optional low-frequency absorption.
When designing the shape of OptiDi, our key objective was to achieve high sound diffusion efficiency with the smallest possible panel thickness.
Every millimetre mattered to us.
A Master of the Background
OptiDi Panel does more than diffuse sound – it can also take centre stage in an interior arrangement.
At Kraków’s Variete Theatre, it proved that acoustic performance and scenic presence can go hand in hand.
Golden Hall
of the Kraków Philharmonic
OptiDi Panel was used as an acoustic treatment supporting sound control in this intimate concert space, without interfering with the representative character of the interior.
Extended Low-Frequency Control
OptiDi Panel can be complemented with a rear absorbing module, extending its performance to include low-frequency control.
Designer
AS Team
Details
OptiDi Panel is an acoustic diffuser made of specially profiled aluminium, providing sound diffusion in the mid and high frequency ranges as well as low-frequency absorption. It is available either as a sound-diffusing version or with an optional absorbing panel.
Standard sizes
- OptiDi Panel:
612 x 1010 x 48 mm - OptiDi Panel with optional sound-absorbing panel:
612 x 1010 x 100 mm - OptiDi Panel In Frame:
650 x 1040 x 100 mm
* dimensions without mounting elements
Weight
- OptiDi Panel: 13 kg
- OptiDi Panel with optional sound-absorbing panel: 17 kg
- OptiDi Panel in Frame: 25 kg
Material
aluminium, wood-based material, mineral wool
Possible finish in any colour from the RAL palette or wood-like varnish.
Designer
Architected Sound Team
Sound absorption coefficient
αw, max = 0.20
Additional information
Technical solution developed in cooperation with the AGH University of Science and Technology in Cracow.
Community design number: 004417723-0001 and 004417723-0002.
Registered Community Design
OptiDi is a product registered with EUIPO – the European Union Intellectual Property Office.
Community design numbers: 004417723‑0001 and 004417723‑0002
A Community design is a legally protected form of industrial design, registered with the European Union Intellectual Property Office (EUIPO), granting exclusive rights to its use across the entire European Union. This protection prevents unauthorized copying and exploitation by third parties, ensuring its originality and safeguarding the interests of its owner.
Possible finish in any colour from the RAL K7 palette or wood-like varnish.
RAL K7 Classic
The most popular colours
Varnish
Non-binding color sample.
Production-related and/or application-related deviations are possible.
Before placing an order, please contact us at info@architected-sound.com in order to verify the colours and their availability.
- concert halls
- philharmonic halls
- theater halls
- opera houses
- rehearsal rooms
- recording studios
- control rooms
- radio and TV emission rooms
- lecture halls
- classrooms
- conference rooms
- offices
- dedicated listening rooms
An individually designed comprehensive acoustic system, taking into account the particular frequency bands.
Possible mobile version.
Different panel thicknesses are available in the hybrid variant due to the absorption needed.
Technical drawing
Fire safety
Possibility of making the system out of materials with flammability class A1.
Sound absorption coefficients of Architected Sound OptiDi Panel
Practical sound absorption coefficient αp
| direct mouting |
A-40 | C-50 | C-100 |
|---|---|---|---|
| frequency 1/1‑oct. |
|
|
|
| 125 Hz | 0.05 | 0.60 | 0.45 |
| 250 Hz | 0.10 | 0.20 | 0.20 |
| 500 Hz | 0.25 | 0.05 | 0.05 |
| 1000 Hz | 0.20 | 0.10 | 0.10 |
| 2000 Hz | 0.15 | 0.15 | 0.15 |
| 4000 Hz | 0.20 | 0.20 | 0.20 |
- A-40: direct mounting, o.d.s. 40 mm*
- C-50: slit 1 mm + mineral wool 50 mm (35 kg/cbm), o.d.s. 90 mm*
- C-100: slit 1 mm + mineral wool 100 mm (35 kg/cbm), o.d.s. 140 mm*
* results obtained from analytical calculations
Sound scattering coefficients of Architected Sound OptiDi Panel
Sound scattering coefficient s
| frequency 1/3‑oct. | |
|---|---|
| 1000 Hz | 0.05 |
| 1250 Hz | 0.13 |
| 1600 Hz | 0.28 |
| 2000 Hz | 0.44 |
| 2500 Hz | 0.53 |
| 3150 Hz | 0.62 |
| 4000 Hz | 0.82 |
| 5000 Hz | 0.90 |
- slit from 0 to 5 mm *
* measurement conducted in accordance to ISO 17497-1:2004
Discover more
Up-Sorber Wall
Sound absorbing system
Up-Sorber Wall is made of specific sound-absorbing filling covered with fabric and it provides variety of colours and textures. Our sound absorbing system offers you various designs to reduce noise in your interior. From single rectangular shapes to sophisticated structures, this unique system gives you options to mount both on walls and ceilings. The greatest advantage of Up-Sorber Wall is you can use it in larger interiors as well as in small rooms, preventing your acoustical environment from flutter echo.
Designer
AS Team
Details
Up-Sorber Wall is a sound absorbing system designed for both walls and ceilings. It can take various of shapes and textures depending on an individual taste and acoustical needs. Up‑Sorber Wall consists of sound absorbing material such as mineral wool and is finished with acoustically transparent textile fabric.
Up‑Sorber Wall structure should be mounted with system battens on a wooden grid. Due to different character of each project the system requires specified mounting. It ensures the reduction of the visibility of the mounting structure to a minimum.
Size
Adjusted to the individual project.
Max width: 1200 mm
Weight
10 kg/m2 at 90 mm depth
Material
textiles, mineral wool / PET / polyethylene foam, PVC strips
Available in broad variety of plain and patterned finishing textiles.
Designer
Architected Sound Team
Sound absorption coefficient
αw, max = 1.0
Please note, that the colors shown are for illustrative purposes only.
Before placing an order, please contact us at info@architected-sound.com in order to verify the colours and their availability.
- lecture rooms
- conference rooms
- classrooms
- recording studios
- emission and sound engineering rooms
- individual and group rehearsal rooms
- waiting rooms
- public and consumer spaces
- open-space
- domestic interiors
The ability to precisely design the sound absorption characteristics by choosing the right fill and cover materials.
It is possible to make inlets for lighting, cables, ventilation grilles, etc.
Technical drawing
Fire safety
Made of materials with flammability class at least B-s1 d0.
Sound absorption coefficients of Architected Sound Up-Sorber Wall
Practical sound absorption coefficient αp
| frequency 1/1-oct. | |
 |
|---|---|---|
| 125 Hz | 0.75 | 0.25 |
| 250 Hz | 1.00 | 0.70 |
| 500 Hz | 1.00 | 0.95 |
| 1000 Hz | 0.95 | 1.00 |
| 2000 Hz | 0.95 | 0.95 |
| 4000 Hz | 0.95 | 0.95 |
- at 90 mm depth of element *
- at 60 mm depth of element *
* results obtained from analytical calculations
Discover more
Up-Sorber Panel
Up-Sorber Panel
Up-Sorber Panel
Up-Sorber Panel Low
Up-Sorber Panel Low
Designed by:
Architected Sound Team
Sound absorbing panel
Up-Sorber Panel (Low) is an acoustic panel that reduces reverberation and improves acoustic comfort, while also bringing visual order to the interior. Its simple upholstered form offers considerable compositional flexibility – from calm, regular layouts to more expressive arrangements. The choice of size and finish colour makes it possible to adapt the product to the character of the space or turn it into a strong decorative feature.
Two versions for different acoustic problems
The product is available in two versions: Up-Sorber Panel and Up-Sorber Panel Low. The standard version is designed to absorb sound across a wide frequency range, while the Low version has been developed for more effective performance in the low-frequency range. This makes it possible to match the solution more precisely to the specific acoustic problems of a given interior.
Up-Sorber Panel (Low) is well suited to offices, conference rooms, educational spaces, foyers, waiting areas, and other interiors where both acoustic comfort and a coherent aesthetic are important.
Acoustic function in an architectural form
The panels improve the acoustic conditions of an interior while remaining a coherent part of its overall composition.
Designer
AS Team
Details
Up-Sorber Panel (Low) is a modular sound-absorbing panel designed for direct wall mounting. It is made of a carefully selected absorbing layer set within a stable structure and finished with high-quality fabric. The product is available in two versions: Up-Sorber Panel and Up-Sorber Panel Low.
The Up-Sorber Panel version is intended to reduce reverberation and absorb sound across a wide frequency range.
The Up-Sorber Panel Low version, thanks to its special construction and carefully selected acoustic filling, has been optimised for performance in the low-frequency range. This makes it possible to choose the most suitable panel variant depending on the nature of the acoustic problem in a given interior.
The product is particularly well suited to existing, already occupied interiors where excessive reverberation and poor acoustic comfort occur. The use of the panels makes it possible to improve acoustic conditions without the need for renovation works or extensive building interventions – installing the panels directly on the wall surface is sufficient.
A wide range of upholstery fabric colours, together with the option to specify panel dimensions, makes it possible to adapt the solution to the requirements and function of a particular interior.
Size
- standard dimensions: 625 × 1025 × 110 mm
- custom dimensions available on request, while maintaining a constant panel thickness of 110 mm
- maximum panel height: 1400 mm
Weight
- weight of a panel in standard dimensions: approx. 10 kg
Material
- wood-based material
- textiles – available in a wide range of colours
- sound-absorbing material
Designer
Architected Sound Team
- lecture rooms
- conference rooms
- classrooms
- recording studios
- emission and sound engineering rooms
- individual and group rehearsal rooms
- waiting rooms
- public and consumer spaces
- open-space
- domestic interiors
Please note, that the colors shown are for illustrative purposes only.
Before placing an order, please contact us at info@architected-sound.com in order to verify the colours and their availability.
The panels can be manufactured in custom dimensions on request, while maintaining a constant thickness of 110 mm.
On request, technological cut-outs can also be made, for example for lighting fixtures.
Technical drawing
Fire safety
Made of materials with flammability class at least B-s1 d0.
Acoustic properties
| Up-Sorber Panel | Up-Sorber Panel Low | |
|---|---|---|
| sound absorption class according to PN-EN ISO 11654 |
A | D |
| weighted sound absorption coefficient according to PN-EN ISO 11654 |
αw = 1,00 | αw = 0,35 (L) |
| Sound Absorption Average according to ASTM C423, 2017 |
SAA = 1,00 | SAA = 0,45 |
| Noise Reduction Coefficient according to ASTM C423, 2017 |
NRC = 1,00 | NRC = 0,45 |
Architected Sound Up-Sorber Panel (Low) – equivalent absorption area
Equivalent absorption area – Aobj
| frequency 1/1 oct. | |
|
|---|---|---|
| 125 Hz | 0,41 | 0,53 |
| 250 Hz | 0,75 | 0,47 |
| 500 Hz | 0,88 | 0,31 |
| 1000 Hz | 0,83 | 0,23 |
| 2000 Hz | 0,83 | 0,17 |
| 4000 Hz | 0,78 | 0,25 |
- Up-Sorber Panel
- Up-Sorber Panel Low
Discover more
Up-Sorber Roll
Sound-absorbing roller blinds
Up-Sorber Roll is expandable sound‑absorbing banner that we designed to ensure quick and automatic regulation of acoustic properties in multi-functional rooms. This product consists of rolled-up fabric of custom designed length to fit particular environment. Up‑Sorber Roll has a control system that provide autonomous and automatic operation.
Due to individually designed control system, setting proper acoustics has never been easier !
Designer
AS Team
Details
Up-Sorber Roll contains an expandable surface made of textile materials, ensuring the regulation of reverberation time in the range of medium and high tones by increasing the acoustic absorption of the interior and eliminating the first reflections of the sound.
Up-Sorber Roll can be made of one or two layers of textile. The latter increases acoustic absorption in low frequencies and allows obtaining maximum uniformity of acoustic conditions in the whole room.
The system is designed to be installed on walls or ceilings. Specialized mounting procedure required due to individual character of each project.
Size
- standard width - 1.3 m
- max width - 2.5 m
- max lenght - 5.0 m
Weight
ca. 26 kg
Material
absorptive fabrics
Available in various sizes and colours according to individual project.
Designer
Architected Sound Team
Sound absorption coefficient
αw, max = 0.65
Please note, that the colors shown are for illustrative purposes only.
Before placing an order, please contact us at info@architected-sound.com in order to verify the colours and their availability.
- multi-functionals rooms
- concert halls
- theaters
- philharmonics
- lecture rooms
- conference rooms
- home listening rooms
- rooms in buildings under the supervision of the conservator
Non-standard length and width possible. Possibility of creating a passive surface that can be made of materials ensuring free air flow, such as steel cables or mesh. The active surface is made of textile materials, also with non‑flammability certificates.
Possibility of backlighting of the lower stiffening beam with battery power supply.
Technical drawing
Wall mounting
Ceiling mounting
Fire safety
Made of materials with flammability class B-s2, d0.
Sound absorption coefficients of Architected Sound Up-Sorber Roll
Practical sound absorption coefficient αp
| frequency 1/1-okt. | |
|---|---|
| 125 Hz | 0.15 |
| 250 Hz | 0.40 |
| 500 Hz | 0.75 |
| 1000 Hz | 0.85 |
| 2000 Hz | 0.65 |
| 4000 Hz | 0.65 |
- distance of the expanded surface from the wall: 100 mm
Discover more
Tilt Wall
Sound reflective panel
Tilt Wall is a wall acoustic system, created to correctly orient the sound wave reflections. Depending on the type of filling material and type of front plate, it’s possible to eliminate the flutter echo effect, achieve a significant improvement in speech intelligibility, and reduce reverberation in a wide, frequency range. Thanks to the slanted frame, the structure could be directed in any direction.
Designer
AS Team
Details
Tilt Wall is a multi-functional wall acoustic system that allows you to direct the sound wave reflections in the desired direction or tune the absorption in a wide range of frequencies. The Tilt Wall frame slants the front plate at an angle of 7° to the wall surface. Due to the uncomplicated installation and low weight, Tilt Wall system can also be used in existing, finished interiors, both on the walls and on the door. It is very useful in cases where components cannot be mounted symmetrically.
Illustration of directing sound waves using Tilt Wall frame
Size
596 × 596 × 100 mm
Weight
up to 8.3 kg
Material
- frame - powder – coated steel
- front plate - HPL, MDF plate, PET or mineral wool
- filling - polyurethane foam, mineral wool
Designer
Architected Sound Team
Illustration of Tilt Wall frame assembly
Tilt Wall acoustic system is available in any colour from the RAL K7 Classic palette.
RAL K7 Classic
- concert halls
- recording studios
- dedicated listening rooms
- conference rooms
- lecture halls
- classrooms
- waiting rooms
- offices
- public and consumer spaces
It is possible to make the Tilt Wall as a sound absorbing system using a front panel made of mineral wool, PET or a hard perforated panel. It is also possible to add a thin openwork plate with a pattern adjusted to the customer’s requirements.
Technical drawing
Fire safety
Possibility of making the diffusing only system out of materials with flammability class B-s1, d0.
Discover more
Tilt Lite
Sound reflective panel
Tilt Lite is an extremely light wall acoustic system, created in order to properly direct the reflections of the sound wave. The 7° inclined mounting bracket enables the front plate to be directed in any direction. Tilt Lite is a universal and individually selected element of acoustic treatment of the interior, which allows you to create interesting visual forms.
Designer
AS Team
Details
Tilt Lite is a wall-mounted, multifunctional acoustic system that allows you to direct the sound wave in the desired direction. The Tilt Lite mounting bracket tilts the front plate at an angle of 7 ° to the wall surface. Due to easy installation and low weight, the Tilt Lite system can also be used in existing, finished interiors. It is also very useful in cases where classic acoustic systems cannot be installed symmetrically.
Illustration of directing sound waves using Tilt Lite panels
Dimensions
- square - 600 × 600 × 98 mm
- triangle - 600 × 520 × 93 mm
- semicircle - 600 × 300 × 79 mm
Weight
- square - up to 3,9 kg
- triangle - up to 2,2 kg
- semicircle - up to 3,3 kg
Material
powder coated steel
front plate - HPL, PET
Designer
Architected Sound Team
Illustration of Tilt Lite panel assembly
Colour guide of Tilt Lite is available on request.
- concert halls
- recording studios
- dedicated listening rooms
- conference rooms
- lecture rooms
- classrooms
- waiting rooms
- offices
- consumer and public spaces
It is possible to make the Tilt Lite as a sound absorbing system using EcoPET as a front panel.
Technical drawing
Fire safety
Possibility of making the diffusing only system out of materials with flammability class B-s1, d0.
Discover more
Panel dźwiękochłonny
Poznajcie nasz przebojowy produkt – płytki akustyczne EcoPET. Dzięki ich minimalistycznej formie, niewielkiej grubości oraz możliwości dowolnego mieszania kolorów i kształtów stworzycie swoją własną, niepowtarzalną ścianę o super MOCY! Siła działania naszych płytek EcoPET wynika ze specyfiki materiału, z którego są wykonane oraz bardzo wysokiej skuteczności tłumienia dźwięków i pochłaniania wszelkich hałasów.
Slotbar
Sound absorbing system
Slotbar is a modular sound-absorbing system developed by Architected Sound. Uniquely arranged natural wooden bars absorb low tone resonance. Its properties result from specifically designed slot system which maintains optimum acoustic conditions and provides innovative shape. The whole structure guarantees absorption in low frequency range. SlotBar can be used as standalone system or in addition to OptiDi.
Simplicity is the key to brilliance!
Designer
AS Team
Details
SlotBar properties allow the absorption of sound in the low frequency range with relatively small thickness of the structure, which is particularly desirable in small sized studio rooms. It is possible to precisely design the range of sound absorption in the low frequencies due to specially developed slot system with a variable gap width, supported by the use of acoustic nonwovens and an invisible layer of material with appropriately selected acoustic properties. Optional installation of teletechnical, electrical equipment and executive modules inside the system.
Size
150 × 1200 × 12 mm
Thickness
Substructure with absorbing material (e.g. mineral wool) is 50-100 mm thick (depending on the absorption needed).
Minimum thickness of a single element: 12 mm
Weight
10 kg/m2 (substructure not included)
Material
MDF
Designer
Architected Sound Team
Sound absorption coefficient
αw, max = 0.60
The SlotBar sound-absorbing system is available in any colour from the RAL K7 Classic palette or natural veneer.
RAL K7 Classic
Veneer
- concert halls
- recording studios
- home listening rooms
- offices
- conference room
- classrooms in musical schools
- consumer spaces
- waiting rooms
Large diversity of sizes in design and installation solutions available, which enables designing and installing the module of external sizes required for current localization.
Technical drawing
Fire safety
Possibility of making the system out of materials with flammability class at least D-s1.
Sound absorption coefficients of Architected Sound SlotBar
Practical sound absorption coefficient αp
| frequency 1/1-oct. |  |
 |
|
|
|---|---|---|---|---|
| 125 Hz | 0.05 | 0.15 | 0.05 | 0.15 |
| 250 Hz | 0.15 | 0.55 | 0.20 | 0.55 |
| 500 Hz | 0.50 | 0.85 | 0.55 | 0.90 |
| 1000 Hz | 0.75 | 0.90 | 0.85 | 0.95 |
| 2000 Hz | 0.90 | 0.90 | 0.95 | 0.95 |
| 4000 Hz | 0.90 | 0.85 | 0.95 | 0.95 |
- percentage share of the slot 1%, mineral wool 100 mm, o.d.s. 112 mm *
- percentage share of the slot 4%, mineral wool 50 mm, o.d.s. 62 mm *
- percentage share of the slot 50%, mineral wool of high density 50 mm, o.d.s. 62 mm *
- percentage share of the slot 50%, mineral wool of medium density 50 mm, o.d.s. 62 mm *
* results obtained from analytical calculations
Discover more
